SPECIFICATIONS





Certification: CE,FCC,UL,pse

Flexible Solar Panel: No

Foldable Solar Panel: Yes

High-concerned chemical: None

Material: Polycrystalline Silicon

Max. Power: 200W

Model Number: SOLAX SE

Module Efficien: 24%

Nominal Capacity: 60/100/200

Number of Panels: 4

Size: 26.4 x 15.6 x 3.2 cm

Type: Solar Panel

is_customized: Yes



 SE60 – 60W Portable Foldable Solar Panel

 100W Solar Panel SE100

Maximum output (ppm): 100W 土5%

Open voltage (Vor): 24.48V

Maximum output voltage (Vm): 20.8V

Short circuit current: 5.33A

Maximum output current: 4.8A

Cell material: Monocrystalline silicon+ETFE

Maximum conversion rate(EFF): 23％-25％

Operating temperature: -20℃～60℃

Unfolded size: 105cm×58.7cm×0.3cm

Folded size: 58.7cm×58.7cm×0.55cm

Weight: 3.8kg

Durability: IP68 rated（waterproof, dustproof, ETFE surface resists scratches）

 200W Solar Panel SE200



Maximum output (ppm): 200W 土5%

Open voltage (Vor): 48.96V

Maximum output voltage (Vm): 41.6V

Short circuit current: 5.33A

Maximum output current: 4.8A

Cell material: Monocrystalline silicon+ETFE

Maximum conversion rate(EFF):23%-25%

Operating temperature: -20°C~60°C

Unfolded size: 205.6cm×58.7cm×0.3cm

Folded size: 55.9cmx58.7cmx2cm

Weight: 7.16kg

Durability: IP68 rated（waterproof, dustproof, ETFE surface resists scratches）

• Wide Compatibility: Designed to work with most portable power stations and solar generators available today. Includes a standard MC4 output with a versatile adapter cable for quick and secure connection.
• High Conversion Efficiency: Built with premium monocrystalline solar cells and a durable ETFE surface layer, delivering an industry-leading conversion efficiency of 23–25% for faster, more reliable charging in real-world conditions.
• Rugged & Weatherproof – IP68 Rated: Fully dust-tight and waterproof (IP68), this solar panel withstands heavy rain, sand, snow, and even temporary submersion. The reinforced ETFE coating resists UV degradation, scratches, and wear—making it truly built for life off the grid.
